This Grade A Head Gasket is a replacement for Bobcat OEM 7030334. A low cost, high quality aftermarket part designed to meet or exceed OEM quality.
Details:
- Is 1 hole, 0.077 mm thickness designed for the engine cylinder head.
- Previous part number was 7030335.
- Order this part and the following part, and follow the procedure for a complete replacement:
- Grade C Head Gasket, 7030336
- Procedure:
- The head gasket thickness needs to be correct. Typically there are three thicknesses available and they have a visual identifier (1, 2, or 3 holes).
- The head gasket thickness is chosen by measuring piston protrusion. Each piston needs to be measured at top dead center. Measure the piston at 2 points, making sure you are not measuring in the valve relief areas, and average the readings.
- Once done, average all 4 piston numbers and choose gasket from the table.
Compatible with the following Bobcat Models:
- Compact Excavators: E42, E45, E50, E55, E85, E57W
- Compact Track Loaders: T450, T550, T590, T595, T630, T650
- Skid Steer Loaders: S510, S530, S550, S570, S590, S595, S630, S650
- Toolcats: 5600, 5610
